Glass Bottle Interior Spray Coating Solution
Automatic inner spray machine & turnkey coating line for perfume, cosmetic, pharma, wine & food glass bottles. Narrow neck down to 5mm, zero exterior contamination, PLC recipe control, UV / water-based / solvent compatible.
Solution Overview
Geetech: Precision Interior Spray Coating for Glass Bottles
Designed for narrow-neck glass containers, Geetech interior spray machines use extended-nozzle guns and multi-axis positioning to coat the inner wall with lacquer, paint, or UV material. From standalone units to fully automated turnkey lines, we deliver high-flexibility, low-waste internal coating solutions for perfume, cosmetic, pharmaceutical, wine, and food-grade glass bottles.
Narrow Neck Expert
Handles bottle neck diameters down to 5mm. Extended nozzle reaches deep into the bottle, ensuring full coverage at shoulder and bottom with zero dead zones.
Zero Exterior Contamination
Negative-pressure recovery combined with external masking fixtures ensures the bottle exterior stays completely clean during interior spraying.
Multi-Coating Compatible
Supports solvent-based, water-based, and UV-cure coatings. One platform handles primer, basecoat, and clearcoat for diverse production needs.
Pain Points & Our Solutions
Match your bottleneck to the right configuration — no over-engineering, no missed coverage.
Common Pain Points
- Narrow neck (≤5mm) — gun can't reach, shoulder dead zone
- Overspray contaminates bottle exterior
- Long changeover, manual re-teaching for each SKU
- High paint waste, VOC emission concerns
- Food / pharma grade safety requirement
- Hard to integrate with existing line
Geetech Solutions
- Extended long-nozzle gun + multi-axis positioning, deep to bottom, full shoulder coverage
- Negative-pressure recovery + external masking, zero exterior contamination
- PLC recipe memory, one-click SKU switch, changeover ≤15 min
- Water-based / UV compatible, closed-loop recovery, waste reduced 30%+
- 304/316 stainless steel contact parts, food-grade coating optional
- Inline / rotary / spindle layouts, custom to your plant
Process Route & Line Layout
Standard turnkey interior spray line — every station engineered around the bottle, not the other way around.
Loading
Automatic bottle feeding / manual loading
Dust Removal
Electrostatic dedusting
Interior Spray
Long-nozzle internal gun
Curing
UV oven / Hot air / IR
Unloading
Synchronized discharge
Line Layout & Gallery
Conveyor: chain / spindle / rotary turntable. Spray booth: dry-type, negative pressure. Recovery: closed-loop paint recovery. Download layout PDF / DWG →
Core Specifications
Structured parameters for quick comparison and RFQ. Values are standard ranges — final spec confirmed against your bottle drawing.
| Parameter | Details |
|---|---|
| Applicable bottles | Glass bottles, jars, vials, flasks |
| Neck diameter | 5mm – 50mm (smaller on request) |
| Bottle height | 40mm – 300mm (extendable) |
| Coating type | Solvent-based / Water-based / UV-cure |
| Spray gun | Long-nozzle internal gun, single / dual / triple |
| Control system | PLC + Touchscreen, recipe memory |
| Conveyor speed | 0–10 m/min (adjustable) |
| Output | 500 – 6,000 pcs/h (by configuration) |
| Curing | UV oven / Hot air oven / IR |
| Material | Stainless steel 304/316 contact parts |
| Power / Air | 380V / 3P / 50Hz (custom) · 0.6–0.8 MPa |
| Certification | CE / ISO available |
| Lead time | 30–60 days |
Last verified: 2026-08. For project-specific parameters, contact engineering — see RFQ form.
Compliance & Export Readiness
For procurement, ESG and plant managers — documentation and standards support included.
- CE certification — full CE compliance for European market
- ISO 9001 quality management system
- Export documents — HS code 8424.89 / 8424.30 (spraying machinery)
- Coating compliance — food-grade / pharma-grade lacquer support, SGS report available
- Emission control — closed-loop paint recovery, VOC reduction 30%+
- Documentation pack — operation manual, electrical diagram, spare parts list, layout drawing
Investment & Operating Cost
Three configuration tiers — choose by capacity and automation level. Figures are reference ranges; final quote against RFQ.
| Tier | Configuration | Capacity | Reference Investment |
|---|---|---|---|
| Essential | Single interior spray machine | 200–800 pcs/h | On request |
| Standard | Auto spray + UV cure line | 800–2,500 pcs/h | On request |
| Automatic | Inline / spindle turnkey line | 2,500–6,000 pcs/h | On request |
- Payback via labor reduction + paint savings; typical ROI case available on request
- Paint waste reduced 30%+ with closed-loop recovery
- Payment milestones: design → manufacturing → installation → commissioning
- Lead time 30–60 days; on-site installation & operator training included
Industry Cases
Standardized case cards — pain point → configuration → result. (Customer names anonymized where required.)
5ml Perfume Vial Interior Spray Line
Pain: 5mm neck, shoulder dead zone, exterior contamination.
Config: dual-gun interior machine + UV cure.
Result: uniform inner coat, zero exterior stain, output 1,200 pcs/h.
Pharma Vial Inner Surface Spray
Pain: deep cavity, food/pharma grade required.
Config: 3-axis interior spray + stainless 316 contact.
Result: SGS-compliant coating, consistent film thickness.
Whisky Bottle Internal Lacquer Line
Pain: anti-sulfide penetration, high-volume.
Config: inline interior spray line + thermal cure.
Result: food-grade inner barrier, 3,000 pcs/h stable.
Delivery & Service Guarantee
Turnkey support across the full equipment lifecycle.
Requirement
Drawing review & technical survey
3D Proposal
Layout & line simulation
Manufacturing
Build & factory test
Installation
On-site install & commissioning
Training
Operator & maintenance training
Warranty
Remote + on-site support, spare parts supply
24/7 Support
Remote diagnosis & rapid on-site response.
Spare Parts
Express worldwide shipping to minimize downtime.
Integration
MES / ERP interface support on request.
FAQ
Answers to questions that commonly block an RFQ — so you can inquire with confidence.
What is the minimum neck diameter your machine can handle?
Standard down to 5mm. Smaller openings supported by custom long-nozzle solutions.
Can the machine spray both inside and outside of the bottle?
Yes. We offer interior-only machines and combined inside & outside spray lines.
What types of coating are compatible?
Solvent-based paint, water-based lacquer, and UV-cure coating. Gun and curing method are matched to your coating.
How to avoid overspray on the bottle exterior?
Long-nozzle internal guns with precise positioning, external masking fixtures, and negative-pressure recovery ensure zero exterior contamination.
Can an existing manual line be upgraded instead of replaced?
Often yes — send us your current layout and bottle drawing via the RFQ form for a retrofit assessment.
What is the production capacity?
500–6,000 bottles/h depending on configuration.
Do you provide installation and training?
Yes. Turnkey service includes on-site installation, commissioning, and operator training; 24/7 remote support.
What is the HS code for export?
Typically 8424.89 or 8424.30 (spraying machinery).
