Product Introduction
Curing oven is the core unit to fix paint film. It includes hot‑air circulation oven for powder & baking paint, IR infrared oven for fast partial curing, UV curing machine for second‑level instant curing. Qualified temperature uniformity is ±5℃.
Process Flow
Painted workpiece enters oven → Heating section → Holding curing section → Slow cooling section → Discharge. IR oven supports multi‑zone temperature control. Powder coating:180‑220℃×10min; liquid paint:80℃×30min.
Main Components
Stainless steel inner chamber + rock wool insulation ≥100mm + air knife circulation + PID‑PLC temperature control + IR quartz / ceramic heater + mesh / chain conveyor + waste gas outlet.
Price Range
Small tunnel oven:0.3‑1k USD; Standard IR oven:3‑8k USD; Medium hot‑air curing oven:8‑25k USD; Large powder curing oven:20‑60k USD.
Chinese Manufacturers
① Geetech (self‑produced UV & IR curing section) ② Yancheng Wanyan (tunnel & preheat oven) ③ Shanghai Yintian (multi‑zone temp oven) ④ Suzhou Sibitai (drying line).
Purchasing Tips
Inspect insulation thickness and duct sealing, heat leakage leads to high power cost. Review one‑month oven temperature log. Write acceptance clause: max temperature deviation ≤±5℃ inside chamber.
Contact Geetech
sales@geetech.co. Get free selection table IR VS Hot‑air VS UV and oven thermal balance calculation document.
